○ MINUTES
○ SECONDS
○ UTC OFFSET
○ DST ENABLED
○ CLK NOT SET WRN
● VIEW DATE/TIME
● VERSION INFO
○ DGC-2020
■ FIRMWARE VERSION
■ BOOT CODE VERSION
■ SERIAL NUMBER
■ PART NUMBER
■ MODEL NUMBER
■ LANGUAGE VERSION
■ LANGUAGE PART NUM
■ STYLE CODE
○ LSM-2020 (Visible when LSM-2020 is enabled.)
■ VERSION INFO
□ FIRMWARE VERSION
□ BOOT CODE VERSION
■ TCP/IP SETTINGS
□ IP ADDRESS
□ SUBNET MASK
□ GATEWAY ADDRESS
□ DHCP ENABLE
○ CEM-2020 (Visible when CEM-2020 is enabled.)
■ FIRMWARE VERSION
■ BOOT CODE VERSION
■ SERIAL NUMBER
■ PART NUMBER
■ MODEL NUMBER
■ BUILD DATE
○ AEM-2020 (Visible when AEM-2020 is enabled.)
■ FIRMWARE VERSION
■ BOOT CODE VERSION
■ SERIAL NUMBER
■ PART NUMBER
■ MODEL NUMBER
■ BUILD DATE
COMMUNICATIONS
● CAN Bus SETUP
○ CAN Bus SETUP
■ CAN Bus ENABLE
■ DTC ENABLE (Visible when CAN bus is enabled.)
■ SPN CONV METHOD (Visible when CAN bus is enabled.)
■ CAN Bus ADDR (Visible when CAN bus is enabled.)
■ ECU OPT SLCT (Visible when CAN bus is enabled.)
■ ECU PULSING (Visible when CAN bus is enabled.)
■ ENG SHTDN TM (Visible when CAN bus is enabled.)
■ PLS CYCL TM (Visible when CAN bus is enabled.)
■ ECU SET TM (Visible when CAN bus is enabled.)
■ RESP TIMEOUT (Visible when CAN bus is enabled.)
○ ECU SETUP (Visible when CAN bus is enabled.)
■ ECU CONF
■ GEN DATA TRANSMIT (Visible when ECU is configured for Standard, Volvo Penta, MTU
ADEC, GM/Doosan, Cummins, or MTU Smart Connect.)
■ ENGINE PARAM XMT
■ TRIP RESET (Visible when ECU is configured for Standard, Volvo Penta, MTU ADEC,
GM/Doosan, Cummins, or MTU Smart Connect.)
■ DPF REGENRATE SETUP (Visible when ECU is configured for Standard, Volvo Penta, MTU
ADEC, GM/Doosan, Cummins, or MTU Smart Connect.)
□ DPF MANUAL REGEN
□ DPF REGEN DISABLE
■ SPEED SELECT (Visible when ECU is configured for Volvo Penta.)
■ ACCEL POSITION (Visible when ECU is configured for Volvo Penta.)
2-12 DGC-2020 Human-Machine Interface 9400200990 Rev X
