DGC-2020 Modbus
™ Communication
B-15
Register
Description
Type
Units
Scaling
Factor
R/W
Range
43356
User Configurable Input 14 Config Type
Int32
N/A
N/A
RW
0 = None
1 = Alarm
2 = Pre-
alarm
43358
User Configurable Input 14 Time Delay
Int32
Second
N/A
RW
0 - 300
43360-62
RESERVED
43364
User Configurable Input 15 Config Type
Int32
N/A
N/A
RW
0 = None
1 = Alarm
2 = Pre-
alarm
43366
User Configurable Input 15 Time Delay
Int32
Second
N/A
RW
0 - 300
43368-70
RESERVED
43372
User Configurable Input 16 Config Type
Int32
N/A
N/A
RW
0 = None
1 = Alarm
2 = Pre-
alarm
43374
User Configurable Input 16 Time Delay
Int32
Second
N/A
RW
0 - 300
43376-408
RESERVED
43410
ATS Contact Input
Int32
N/A
N/A
RW
-1 = None
0 = Input 1
1 = Input 2
2 = Input 3
3 = Input 4
4 = Input 5
5 = Input 6
6 = Input 7
7 = Input 8
8 = Input 9
9 = Input 10
10 = Input 11
11 = Input 12
12 = Input 13
13 = Input 14
14 = Input 15
15 = Input 16
43412
RESERVED
43414
Single Phase Connection Override Contact
Input
Int32
N/A
N/A
RW
-1 = None
0 = Input 1
1 = Input 2
2 = Input 3
3 = Input 4
4 = Input 5
5 = Input 6
6 = Input 7
7 = Input 8
8 = Input 9
9 = Input 10
10 = Input 11
11 = Input 12
12 = Input 13
13 = Input 14
14 = Input 15
15 = Input 16
43416
RESERVED
