the DGC-2020 does not have descriptive information about an SPN and FMI that was received, the
description will display as “NO TEXT AVAILABLE”.
Table 3-5. DTCs Displayed by the DGC-2020 (FMI Strings)
FMI String Displayed Description
0 DATA HI MOST SEVERE Data is higher than expected at the most severe level
1 DATA LO MOST SEVERE Data is lower than expected at the most severe level
2 DATA ERRATIC OR BAD Data is erratic, intermittent, or incorrect
3 VOLTS HI OR SHORTED Measured voltage is higher than expected or shorted to a high source
4 VOLTS LO OR SHORTED Measured voltage is lower than expected or shorted to a low source
5 CURRENT LO OR OPEN Measured current is lower than expected or the circuit is open
6 CURRENT HI OR SHORTED Measured current is higher than expected or shorted
7 MECHANICAL SYSTM ERR Mechanical system error
8 FREQ OR PWM ERROR Error in frequency, pulse width or period of any frequency or PWM signal
is outside its predetermined limits.
9 ABNORMAL UPDATE RATE Update rate of parameter is abnormal.
10 DATA RT OF CHG ERR Rate of change of data is abnormal.
11 FAILURE CAUSE UNKNOWN String indicating failure cause is unknown.
12 BAD INTELLIGNT DEVICE Engine ECU is reporting that an intelligent device or component failure
has been detected.
13 OUT OF CALIBRATION Device or parameter is out of calibration.
14 CONSULT ENG MFG DATA User should consult engine manufacturer's data.
15 DATA HI LST SEVERE Data is higher than expected at the least severe level.
16 DATA HI MODERATE SVR Data is higher than expected at a moderately severe level.
17 DATA LO LST SEVERE Data is lower than expected at the least severe level.
18 DATA LO MODERATE SVR Data is lower than expected at a moderately severe level.
19 NETWORK DATA ERR String Indicating Network Data contained an error indication.
20 DATA DRIFTED HI Data has drifted to a value higher than the maximum valid value.
21 DATA DRIFTED LO Data has drifted to a value lower than the minimum valid value.
22 FMI RESERVED BY SAE This FMI is reserved by the Society of Automotive Engineers.
23 FMI RESERVED BY SAE This FMI is reserved by the Society of Automotive Engineers.
24 FMI RESERVED BY SAE This FMI is reserved by the Society of Automotive Engineers.
25 FMI RESERVED BY SAE This FMI is reserved by the Society of Automotive Engineers.
26 FMI RESERVED BY SAE This FMI is reserved by the Society of Automotive Engineers.
27 FMI RESERVED BY SAE This FMI is reserved by the Society of Automotive Engineers.
28 FMI RESERVED BY SAE This FMI is reserved by the Society of Automotive Engineers.
29 FMI RESERVED BY SAE This FMI is reserved by the Society of Automotive Engineers.
30 FMI RESERVED BY SAE This FMI is reserved by the Society of Automotive Engineers.
31 CONDTN EXST OR FMI NA If the SPN refers to a parameter with status of ON or OFF, an FMI of 31
indicates ON. If the SPN refers to a parameter with a numeric value, an
FMI of 31 indicates that there is no FMI to describe the parameter’s
condition.
Table 3-6. DTCs Displayed by the DGC-2020
SPN FMI String Displayed Description
27 # EGR1 VALVE POSITN Caption Indicating EGR1 Valve Position
28 3 Throttle Volt HI Throttle Voltage High
28 4 Throttle Volt LO Throttle Voltage Low
28 14 Throttle Volt OOR Throttle Input Voltage Out of Range
29 # ACCEL PEDAL 2 POSITN Caption string for accelerator pedal 2 position
29 3 Throttle Volt HI Throttle Voltage High
29 4 Throttle Volt LO Throttle Voltage Low
29 14 Throttle Volt OOR Throttle Input Voltage Out of Range
51 # ENG THROTTLE POSITN Caption Indicating Engine Throttle Position
52 15 INTERCOOLER TEMP HI Engine Intercooler Temperature is above the HIGH threshold
69 # 2 SPEED AXLE SWITCH Caption Indicating Two Speed Axle Switch
