HEIDENHAIN TNC 640 (34059x-05) - Manual (Page 114)

Programming: Fundamentals, File Management
3.3 File Management: Fundamentals
3
114
TNC 640 | User's Manual
HEIDENHAIN Conversational Programming | 1/2015
3.3 File Management: Fundamentals
Files
Files in the TNC Type
Programs
in HEIDENHAIN format
in DIN/ISO format .H
.I
Compatible Programs
HEIDENHAIN Unit Programs
HEIDENHAIN Contour Programs .HU
.HC
Tables for
Tools
Tool changers
Datums
Points
Presets
Touch probes
Backup files
Dependent files (e.g. structure items)
Freely definable tables
Pallets
Turning tools .T
.TCH
.D
.PNT
.PR
.TP
.BAK
.DEP
.TAB
.P
.TRN
Texts as
ASCII files
Protocol files
Help files .A
.TXT
.CHM
CAD files as
ASCII files DXF
.IGES
.STEP
When you write a part program on the TNC, you must first enter a
program name. The TNC saves the program to the internal memory
as a file with the same name. The TNC can also save texts and
tables as files.
The TNC provides a special file management window in which
you can easily find and manage your files. Here you can call, copy,
rename and erase files.
You can manage an almost unlimited number of files with the TNC.
The available memory is at least
21 GB . A single NC program can
be up to 2 GB in size.
Depending on the setting, the TNC generates a
backup file (*.bak) after editing and saving of NC
programs. This can reduce the memory space
available to you.
