Moving the machine axes 15.2
15
TNC 640 | User's Manual
HEIDENHAIN Conversational Programming | 1/2015
529
Generating a complete traversing block
Your machine tool builder can assign any function
to the "Generate NC block" handwheel key. Refer to
your machine manual.
Select the
Positioning with MDI operating mode
If required, use the arrow keys on the TNC keyboard to select
the NC block after which the new traversing block is to be
inserted.
Activate the handwheel
Press the “Generate NC block” handwheel key: The TNC
inserts a complete traversing block containing all axis positions
selected through the MOD function.
Features in the program run modes of operation
You can use the following functions in the Program Run modes of
operation:
NC start (handwheel NC-start key)
NC stop (handwheel NC-stop key)
After the NC-stop key has been pressed: Internal stop
(handwheel soft keys
MOP and then STOP)
After the NC-stop key has been pressed: Manual axis traverse
(handwheel soft keys
MOP and then MAN)
Returning to the contour after the axes were moved manually
during a program interruption (handwheel soft keys
MOP
and then REPO). Operation is by handwheel soft keys, which
function similarly to the control-screen soft keys, see "Returning
to the contour", page 607
On/off switch for the Tilted Working Plane function (handwheel
soft keys
MOP and then 3D)
