Graphics 17.1
17
TNC 640 | User's Manual
HEIDENHAIN Conversational Programming | 1/2015
591
Move the sectional planes
Select the functions for shifting the sectional
plane. The TNC offers the following soft keys:
Soft keys Function
Shift the vertical sectional plane to the right
or left
Shift the vertical sectional plane forward or
backward
Shift the horizontal sectional plane upwards
or downwards
The position of the sectional planes is visible during shifting.
The default setting of the sectional plane is selected so that it lies
in the working plane in the workpiece center and in the tool axis on
the top surface.
Return sectional planes to default setting:
Select the function for resetting the sectional
planes.
