Programming: Multiple Axis Machining
12.2 The PLANE Function: Tilting the working plane (Software Option 8)
12
444
TNC 640 | User's Manual
HEIDENHAIN Conversational Programming | 1/2015
Abbreviations used:
PROJECTED Projected
PROPR Principle plane
PROMIN
Minor plane
PROMIN
Rotation
Defining the working plane with the Euler angle:
PLANE EULER
Application
Euler angles define a machining plane through up to three
rotations about the respectively tilted coordinate system . The
Swiss mathematician Leonhard Euler defined these angles. When
applied to the machine coordinate system, they have the following
meanings:
Precession angle:
EULPR Rotation of the coordinate system
around the Z axis
Nutation angle:
EULNU Rotation of the coordinate system
around the X axis already shifted by the
precession angle
Rotation angle:
EULROT Rotation of the tilted machining plane
around the tilted Z axis
Before programming, note the following
Parameter description for the positioning behavior:
see "Specifying the positioning behavior of the
PLANE function", page 453.
