Generating a graphic for an existing program
Use the arrow keys to select the block up to which you want the
graphic to be generated, or press
GOTO and enter the desired
block number
To generate graphics, press the
RESET + START
soft key
Additional functions:
Soft key Function
Generate a complete graphic
Generate programming graphic blockwise
Generate a complete graphic or complete it after
RESET + START
Stop the programming graphics. This soft key
only appears while the TNC is generating the
programming graphics
Select plan view
Select front view
Select side view
