Additional functions 9.8
9
TNC 640 | User's Manual
HEIDENHAIN Conversational Programming | 1/2015
323
Group name, ID no. Number Index Meaning
Values programmed immediately
after TOOL CALL, 60 1 - Tool number T
2 - Active tool axis
0 = X 6 = U
1 = Y 7 = V
2 = Z 8 = W
3 - Spindle speed S
4 - Oversize for tool length DL
5 - Tool radius oversize DR
6 - Automatic TOOL CALL
0 = Yes, 1 = No
7 - Tool radius oversize DR2
8 - Tool index
9 - Active feed rate
Values programmed immediately
after TOOL DEF, 61 1 - Tool number T
2 - Length
3 - Radius
4 - Index
5 - Tool data programmed in TOOL DEF
1 = Yes, 0 = No
Active tool compensation, 200 1 1 = without
oversize
2 = with
oversize
3 = with oversize
and
Oversize from
TOOL CALL Active radius
2 1 = without
oversize
2 = with
oversize
3 = with oversize
and
Oversize from
TOOL CALL Active length
3 1 = without
oversize
2 = with
oversize
3 = with oversize
and
Oversize from
TOOL CALL Rounding radius R2
