Manual operation and setup
15.4 Optional safety concept (Functional safety FS)
15
534
TNC 640 | User's Manual
HEIDENHAIN Conversational Programming | 1/2015
Checking the axis positions
This function must be adapted to the TNC by your
machine manufacturer. Refer to your machine
manual.
After switch-on the TNC checks whether the position of an axis
matches the position directly after switch-off. If a deviation occurs
this axis is displayed red in the position display. Axes that are
marked red can no longer be moved while the door is opened.
In such cases you must approach a test position for the axes in
question. Proceed as follows:
Select the
Manual Operation mode
Execute the approach with NC Start to move the axes in the
sequence shown
When the test position has been reached, the TNC asks
whether the position was approached correctly: Confirm
with the OK soft key if the TNC approached the test position
correctly, and with END if the TNC approached the position
incorrectly.
If you confirmed with OK, you must confirm the correctness
of the test position again with the permissive button on the
machine operating panel
Repeat this procedure for all axes that you want to move to the
test position
Danger of collision!
Approach the test positions in such a way that no
collision between tool and the workpiece or the
clamping devices can occur. If necessary, pre-
position the axes manually.
The location of the test position is specified by your
machine tool builder. Refer to your machine manual.
Activating feed-rate limitation
When the F LIMITED soft key is set to ON, the TNC limits the
maximum permissible axis speeds to the specified, safely limited
speed.
Select the
Manual Operation mode
Scroll to the last soft-key row
Switch on/off feed rate limit
