Graphically testing the first part 1.4
1
TNC 640 | User's Manual
HEIDENHAIN Conversational Programming | 1/2015
63
Choosing the program you want to test
Press the
PGM MGT key: The TNC opens the file
manager
Press the
LAST FILES soft key: The TNC opens a
pop-up window with the most recently selected
files
Use the arrow keys to select the program that you
want to test. Load with the ENT key
Further information on this topic
Selecting a program: see "Working with the File Manager",
page 117
Selecting the screen layout and the view
Press the key for selecting the screen layout. The
TNC shows all available alternatives in the soft-key
row
Press the
PROGRAM + GRAPHICS soft key: In
the left half of the screen the TNC shows the
program; in the right half it shows the workpiece
blank
Press the
FURTHER VIEW OPTIONS soft key
Shift the soft-key row and select the desired view
by soft key
The TNC features the following views:
Soft keys Function
Volume view
Volume view and tool paths
Tool paths
Further information on this topic
Graphic functions: see "Graphics ", page 584
Running a test run: see "Test Run", page 596
