Additional functions 9.8
9
TNC 640 | User's Manual
HEIDENHAIN Conversational Programming | 1/2015
325
Group name, ID no. Number Index Meaning
Traverse range, 230 2 1 to 9 Negative software limit switch in axes 1 to
9
3 1 to 9 Positive software limit switch in axes 1 to
9
5 - Software limit switch on or off:
0 = on, 1 = off
Nominal position in the REF
system, 240 1 1 X axis
2 Y axis
3 Z axis
4 A axis
5 B axis
6 C axis
7 U axis
8 V axis
9 W axis
Current position in the active
coordinate system, 270 1 1 X axis
2 Y axis
3 Z axis
4 A axis
5 B axis
6 C axis
7 U axis
8 V axis
9 W axis
Interpretation of coordinates in
turning operation, 310 20 1 to 3
(X, Y, Z) Coordinates are give with respect to:
0 = diameter, -1 = radius
