Functions of the TNC 640 and the iTNC 530 compared 19.5
19
TNC 640 | User's Manual
HEIDENHAIN Conversational Programming | 1/2015
691
Function TNC 640 iTNC 530
Datum table:
Sorting function by values
within an axis Available Not available
Resetting the table Available Not available
Hiding axes that are not
present Available Available
Switching the list/form view Switchover via split-screen key Switchover by toggle soft key
Inserting individual line Allowed everywhere,
renumbering possible after
request. Empty line is inserted,
must be filled with zeros
manually Only allowed at end of table.
Line with value 0 in all columns
is inserted
Transfer of actual position
values in individual axis to the
datum table per keystroke Not available Available
Transfer of actual position
values in all active axes to the
datum table per keystroke Not available Available
Using a key to capture the last
positions measured by TS Not available Available
FK free contour programming:
Programming of parallel axes With X/Y coordinates,
independent of machine type;
switchover with
FUNCTION
PARAXMODE
Machine-dependent with the
existing parallel axes
Automatic correction of relative
references Relative references in contour
subprograms are not corrected
automatically All relative references are
corrected automatically
