Programming: Data Transfer from CAD Files

7.3

DXF converter (Option #42)

7

262

TNC 640 | User's Manual

HEIDENHAIN Conversational Programming | 1/2015

Opening a DXF file

Select the

Programming mode of operation

Select File functions.

In order to see the soft-key menu for selecting the
file type to be displayed, press the

SELECT TYPE

soft key

In order to show all CAD files, press the

SHOW

CAD soft key
Select the directory in which the CAD file is saved

Select the desired CAD file

Load it with the

ENT key. The TNC starts the DXF

converter and shows the contents of the file on
the screen. The TNC shows the layers in the list
view window, and the drawing in the graphics
window
