Programming: Q Parameters
9.8 Additional functions
9
324
TNC 640 | User's Manual
HEIDENHAIN Conversational Programming | 1/2015
Group name, ID no. Number Index Meaning
Active transformations, 210 1 - Basic rotation in MANUAL OPERATION
mode
2 - Programmed rotation with Cycle 10
3 - Active mirrored axis
0: Mirroring not active
+1: X axis mirrored
+2: Y axis mirrored
+4: Z axis mirrored
+64: U axis mirrored
+128: V axis mirrored
+256: W axis mirrored
Combinations = Sum of individual axes
4 1 Active scaling factor in X axis
4 2 Active scaling factor in Y axis
4 3 Active scaling factor in Z axis
4 7 Active scaling factor in U axis
4 8 Active scaling factor in V axis
4 9 Active scaling factor in W axis
5 1 3-D ROT A axis
5 2 3-D ROT B axis
5 3 3-D ROT C axis
6 - Tilted working plane active / inactive (–1/0)
in a Program Run operating mode
7 - Tilted working plane active / inactive (–1/0)
in a Manual operating mode
Active datum shift, 220 2 1 X axis
2 Y axis
3 Z axis
4 A axis
5 B axis
6 C axis
7 U axis
8 V axis
9 W axis
