Screen layout for executing pallet tables
You can have the TNC display the program contents and pallet file
contents on the screen together by selecting the screen layout
PROGRAM + PALLET. During execution, the TNC then shows
program blocks to the left and the pallet to the right. To check the
program contents before execution, proceed as follows:
Select a pallet table
With the arrow keys, choose the program you would like to
check
Press the
OPEN PGM soft key: the TNC displays the selected
program on the screen. You can now page through the program
with the arrow keys
To return to the pallet table: Press the
OPEN PROGRAM soft key
again
