MOD functions
18.11 Ethernet interface
18
634
TNC 640 | User's Manual
HEIDENHAIN Conversational Programming | 1/2015
Select the
Internet tab.
Setting Meaning
Proxy Direct connection to Internet /NAT: The
control forwards Internet inquiries to the
default gateway and from there they must
be forwarded through network address
translation (e.g.. if a direct connection to a
modem is available)
Use proxy: Define the Address and Port
of the Internet router in your network, ask
your network administrator for the correct
address and port
TelemaintenanceThe machine manufacturer configures the
server for telemaintenance here. Changes
must always be made in agreement with
your machine tool builder
Select the
Ping/Routing tab to enter the ping and routing
settings:
Setting Meaning
Ping
In the
Address: field, enter the IP number
for which you want to check the network
connection. Input: four numerical values
separated by periods, e.g.
160.1.180.20.
As an alternative, you can enter the name of
the computer whose connection you want to
check
Press the
Start button to begin the test.
The TNC shows the status information in
the Ping field
Press the
Stop button to conclude the test
Routing
For network specialists: Status information of
the operating system for the current routing
Press the
Update button to refresh the
routing information
Select the
NFS UID/GID tab to enter the user and group
identifications:
Setting Meaning
Set UID/GID
for NFS shares
User ID: Definition of which user
identification the end user uses to access
files in the network. Ask your network
specialist for the proper value
Group ID: Definition of the group
identification with which you access
files in the network. Ask your network
specialist for the proper value
