111
Note
 Screen 2 funciton is null if tour is in process. Please disable tour funciton first,
 Right now, the screen 2 operation can only be realized on the navigation bard. The operations on the
right-click menu are for screen 1 only.
4.3.3 Output Screen
Select corresponding window-split mode and output channels.
4.3.4 Tour
Click button to enable tour, the icon becomes , you can see the tour is in process.
4.3.5 PTZ
Click , system goes to the PTZ control interface. Please refer to chapter 4.7.2.
4.3.6 Color
Click button , system goes to the color interface. Please refer to chapter 4.6.4.1.
Please make sure system is in one-channel mode.
4.3.7 Search
Click button , system goes to search interface. Please refer to chapter 4.9.2
4.3.8 Alarm Status
Click button , system goes to alarm status interface. It is to view device status and channel status.
Please refer to chapter 4.15.1.4.
4.3.9 Channel Info
Click button , system goes to the channel information setup interface. It is to view information of the
corresponding channel. See Figure 4-11.
Figure 4-11
