242
Copy
Click it; you can copy current channel setup to other channel(s).
5.8.1.3.3 Video Overlay
The video overlay interface is shown as in Figure 5-23.
Figure 5-23
Please refer to the following sheet for detailed information.
Parameter
Function
Cover-area
Check Preview or Monitor first.
Click Set button, you can privacy mask the specified video in the
preview or monitor video.
System max supports 4 privacy mask zones.
Time Title
You can enable this function so that system overlays time
information in video window.
You can use the mouse to drag the time title position.
You can view time title on the live video of the WEB or the
playback video.
Channel Title
You can enable this function so that system overlays channel
information in video window.
You can use the mouse to drag the channel title position.
You can view channel title on the live video of the WEB or the
playback video.
5.8.1.3.4 Path
The storage path interface is shown as in Figure 5-24.
Here you can set snap image saved path (
in the preview interface) and the record storage path
(
in the preview interface).The default setup is C:\PictureDownload and C:\RecordDownload.
