249
Please refer to the following sheet for detailed information.
Parameter Function
WLAN type Here you can select 3G network type to distinguish the 3G
module from different ISP. The types include WCDMA，
CDMA1x and etc.
APN/Dial No. Here is the important parameter of PPP.
Authorization It includes PAP,CHAP,NO_AUTH.
Pulse interval It is to set time to end 3G connection after you close extra
stream monitor. For example, if you input 60 here, system ends
3G connection after you close extra stream monitor 60 seconds.
Important
 If the pulse interval is 0, then system does not end 3G connection after
you close the extra stream monitor.
 Pulse interval here is for extra stream only. This item is null if you are
using main stream to monitor.
5.8.2.6.2 Mobile
The mobile setup interface is shown as in Figure 5-33.
Here you can activate (send out
“on”) or turn off (Send out “off”) the 3G connected phone or mobile phone,
or the phone you set to get alarm message.
Check send SMS box and then input the phone number in the receiver column. Click to add one
receiver. Repeat the above steps you can add more phones. Select a phone number and then click ,
you can delete it. Click OK button to complete the setup.
Figure 5-33
