28

Video Output

1-channel VGA analog video output.

HDMI

1-ch HDMI output. Version number is 1.4

Window Split

1/4/8/9/16-window

Audio

Audio Input

1-ch bidirectional talk input

Audio Output

1-ch bidirectional talk output

Audio

Compression

G.711a

Alarm

Alarm Input

2-ch alarm input

Alarm Output

1-ch alarm output

Functio

n

Storage

2 built-in SATA ports.

Multiple-chann

el Playback

Max 8-channel 720P/4-channel 1080P playback at the same time.

Port

and

Indicato

r

RS232 Port

N/A

RS485 port

N/A

USB Port

Two USB2.0 ports at the front panel and one USB3.0 port at the rear

panel. .

Network

Connection

1 RJ45 10/100/1000Mbps self-adaptive Ethernet port and 8 PoE ports.

Power Port

One power port. Input DC 53V--2.3A

Power Button

One button. At the rear panel.

Power On-off

Button

N/A

IR Receiver

Window

Support IR remote control

Clock

Built-in clock.

Indicator Light

One power status indicator light.

One network status indicator light.

One HDD status indicator light.

One alarm status indicator light.

General

Power

Consumption

<30W(Exclude HDD)

Working

Temperature

-10℃~+55℃

Working

Humidity

10℅-90℅

Air pressure

86kpa-106kpa

Dimension

100mm×220mm×146mm
