9
Model 11H Series 11H-P Series
Indicator Light
One power status indicator light.
One network status indicator light.
One HDD status indicator light.
General
Power
Consumption
＜10W (Exclude HDD)
Working
Temperature
﹣10℃～﹢55℃
Working
Humidity
10℅～90℅
Air pressure
86kPa～106kPa
Dimension
325mm×250.58mm×51mm
Weight
0.5kg～1kg (Exclude HDD)
Installation
Mode
Desk installation
1.3.4 NVR41/41-P/41-8P/41-W Series
Model 41 Series 41-P Series 41-8P Series 41-W Series
System System
Resources
4/8/16-ch series product support 4/8/16 HD connection respectively.
Total bandwidth supports 28/56/80Mbps respectively.
OS Embedded Linux real-time operation system
Operation
Interface
WEB/Local GUI
Decode Video Decode
Type
H.264/MJPEG/MJPEG4
Decode
Capability
Max 2-ch 5M 25fps or 4-ch 3M 25fps or 4-ch 1080P 30fps
or 8-ch 720P 30fs
Video Video Input 4/8/16-ch network compression video input
Video Output 1-channel VGA analog video output
HDMI 1-ch HDMI output. Version number is 1.4
Window Split 1/4/8/9/16-window 1/4-window
