269
Parameter Function
Show message System can pop up a message to alarm you in the local
host screen if you enabled this function.
Buzzer Check the box here to enable this function. The buzzer
beeps when an alarm occurs.
Alarm upload System can upload the alarm signal to the centre
(Including alarm centre).
Send Email If you enabled this function, System can send out an email
to alert you when an alarm occurs.
Tour You need to click setup button to select tour channel.
System begins 1-wiindow or multiple-window tour display
among the channel(s) you set to record when an alarm
occurs. See Figure 5-58.
PTZ Activation Here you can set PTZ movement when alarm occurs.
Such as go to preset X. See Figure 5-64.
Snapshot Click setup button to select snapshot channel. See Figure
5-59.
5.8.3.2.2 Net Alarm
The network alarm interface is shown as in Figure 5-65.
Network alarm refers to the alarm signal from the network. System does not anti-dither and sensor type
setup. For setup information, please refer to chapter 5.8.3.2.1.
Figure 5-65
5.8.3.2.3 IPC external alarm
The IPC external alarm interface is shown as in Figure 5-66.
Network alarm refers to the alarm signal from the network. System does not anti-dither and sensor type
