131

The PTZ operation is only valid in one-window mode.

Here you can control PTZ direction, speed, zoom, focus, iris, preset, tour, scan, pattern aux function, light

and wiper, rotation and etc.

Speed is to control PTZ movement speed. The value ranges from 1 to 8.The speed 8 is faster than speed

1. You can use the remote control to click the small keyboard to set.

You can click

and

of the zoom, focus and iris to zoom in/out, definition and brightness.

The PTZ rotation supports 8 directions. If you are using direction buttons on the front panel, there are only

four directions: up/down/left/right.

Figure 4-39

In the middle of the eight direction arrows, there is a 3D intelligent positioning key. See Figure 4-40.

Please make sure your protocol supports this function and you need to use mouse to control.

Click this key, system goes back to the single screen mode. Drag the mouse in the screen to adjust

section size. The dragged zone supports 4X to 16X speeds. It can realize PTZ automatically. The smaller

zone you dragged, the higher the speed.

Figure 4-40

Name Function

key

function

Shortcut

key

Function

key

function

Shortcut

key

Zoom

Near

Far

Focus

Near

Far

Iris

close

Open



In Figure 4-39, click

to open the menu, you can set preset, tour, pattern, scan and etc. See

Figure 4-41.
