Auto-Zone Plus
Section 2
Design Guide 2-45
Optional Remote Link II
The OE419-06 Remote Link II is a 14,400 baud modem that can be used with a
CommLink IV or a computer. It is used to provide remote dial-up communications with
the CommLink IV. When it is used as a computer modem (at the remote computer
location), it connects to the remote computer.
Note: WattMaster will not support any other internal or external modems by other
manufacturers.
The Remote Link connects to the CommLink IV communications interface at the control
system location via a DB9 serial cable. A telephone line connects the Remote Link to the
local phone service. Using another Remote Link modem connected to a computer and
phone service at a remote location, you can monitor and control the system using the
Prism computer front end software. Connection is made by dialing the telephone number
of the job site where the Remote Link is located. See the Remote Link II Technical Guide
Form: WM-RLII-TGD for complete product details and installation instructions.
