Page 121
113
The Summary page appears.
13.
Click Finish.
Adding non-MQC deployment task
Assign priority for the traffic from the computing server and FTP server. The computing server accesses to
the network through Ten-GigabitEthernet1/0/50 of SWD. The FTP server accesses to the network
through Ten-GigabitEthernet1/0/51 of SWD. On SWD, configure the interface priority of interface
Ten-GigabitEthernet1/0/50 to 5, configure the interface priority of interface
Ten-GigabitEthernet1/0/51 to 3.
1.
Click the Service tab.
2.
From the navigation tree, select QoS Manager > QoS Device.
The QoS Device page appears.
3.
Click the Operation icon
for the SWD, and select QoS Configuration Info from the menu.
The QoS Configuration Info page appears.
4.
Clear the Display only interfaces with CBQ deployed box.
5.
Click the Configure link in the Interface Configuration column for Ten-GigabitEthernet1/0/50.
6.
Click Next.
The Set GTS, Priority, and Software Queuing page appears.
7.
Select Configure from the list of Configure or Not in Priority field.
8.
Select 802.1p priority and set its value to 5.
Figure 45 Configure interface priority
9.
Click Next.
The Basic Information page appears.
10.
Configure the following parameters:
{
Task Name—Enter task name ConfigureDot1p5.
