22
QoS function
Subfunction
Parameters
Yellow Action
•
Remark-local-pre-pass—Mark a packet with a local
precedence value and transmit the packet based on the
new local precedence value.
•
Remark-fr-de-pass—Mark a Frame Relay packet with a
DE value and transmit the packet with the new DE value.
•
pass—Transmit a packet.
•
discard—Drop a packet.
•
Remark-ip-pass—Mark a packet with an IP precedence
value and transmit the packet with the new IP precedence
value.
•
Remark-mplsexp-pass—Mark an MPLS packet with an
MPLS EXP value and transmit the packet with the new
MPLS EXP value.
•
Remark-dscp-ass—Mark a packet with a DSCP value
and transmit the packet with the new DSCP value.
•
Remark-dot1p-pass—Mark a packet with an 802.1p
priority value and transmit the packet with the new
802.1p priority value.
•
Remark-atm-clp-pass—Mark an ATM cell with a CLP
value and transmit the ATM cell with the new CLP value.
Red Action
•
Remark-local-pre-pass—Mark a packet with a local
precedence value and transmit the packet based on the
new local precedence value.
•
Remark-fr-de-pass—Mark a Frame Relay packet with a
DE value and transmit the packet with the new DE value.
•
pass—Transmit the packet.
•
discard—Drop the packet.
•
Remark-ip-pass—Mark a packet with an IP precedence
value and transmit the packet with the new IP precedence
value.
•
Remark-mplsexp-pass—Mark an MPLS packet with an
MPLS EXP value and transmit the packet with the new
MPLS EXP value.
•
Remark-dscp-ass—Mark a packet with a DSCP value
and transmit the packet with the new DSCP value.
•
Remark-dot1p-pass—Mark a packet with an 802.1p
priority value and transmit the packet with the new
802.1p priority value.
•
Remark-atm-clp-pass—Mark an ATM cell with a CLP
value and transmit the ATM cell with the new CLP value.
Queue
Queuing Type
•
EF.
•
AF.
•
WFQ.
The three queuing types are all used in class-based queuing
(CBQ).
Packet Drop Type
•
typeTailDrop—Use tail drop for packet drop.
•
typeWred—Use WRED for packet drop.
