Programming Guide for DM3058/DM3058E 5-16
on) currently used.
RANGE1? – Queries the current range selected by main display.
RANGE2? – Queries the current range selected by vice display. If the display is
disabled, an Execute error will generate.
Table 5-2 Range of every function
No. DC V ACV,
Frequency,
Period Resistance ACC DCC Capacitance
1 200 mV 200 mV 200Ω 20mA 200 μA 2nF
2 2 V 2 V 2 kΩ 200mA 2 mA 20nF
3 20 V 20 V 20 kΩ 2 A 20 mA 200nF
4 200 V 200 V 200 kΩ 10 A 200 mA 2μF
5 1000 V dc 750 V dc 2 MΩ NA 2 A 200μF
6 NA NA 20 MΩ NA 10 A 10000μF
7 NA NA 100 MΩ NA NA NA
Return Format:
The query returns the values selected by both the two displays.
4. RATE
Command Format:
RATE <speed>
RATE?
Function:
The commands set and query the measuring speed.
Explanations:
RATE <speed> - Selects the measuring speed to be used from S (2.5 readings/s),
M (20 readings/s) and F (123 readings/s), with case-insensitive. Any other letter
may generate an Execute error.
RATE? – Queries the current measuring speed.
Return Format:
The query returns S, M or F.
