IQOYA SERV/LINK user manual
102
9.2.2.1.3 Delete a SIP account
To delete a SIP account, click the icon on the left of this latter.
Only SIP accounts that are not currently used to register IP codec instances can be deleted.
9.2.2.2 Connections −> IP codecs −> IP codec configuration
This page shows the IP codec instances and allows creating new IP codec instances or editing/deleting existing
ones. The IP codec instances created on this page must be activated to be operational and to appear in the
codec mosaic of the “Operations” page.
This page shows the following parameters for each IP codec instance:
● Audio I/O : The audio I/Os associated with the IP codec instance.
● RTP port : The port used by the the IP codec instance to listen to the IP audio stream coming from the
remote party.
● Contact name : The display names of the SIP accounts used to register the IP codec instance with SIP
servers (only SIP is activated for this instance). There can be up to 2 registrations per IP codec instance.
● SIP address : The SIP addresses of the IP codec instance, one per registration.
● Status : The status of the IP codec instance is empty when the IP codec instance is disabled else the
possible statuses are:
○ “Registered” : SIP is activated and the IP codec instance is successfully registered with the SIP
server.
○ An error message in red: SIP is activated and the IP codec instance fails to register with the SIP
server. The possible error messages are:
- “Invalid address, check DNS” : the SIP domain is wrong,
- “Unknown name or user” : the SIP account name, the SIP authentication name or the SIP
authentication password is wrong.
- “No remote response” : The SIP server is unreachable.
○ “Not registered” : The user has manually unregistered the IP codec instance.
○ “Ready” : SIP is not activated and the IP codec instance is ready for a symmetric RTP connection.
