IQOYA SERV/LINK user manual
64
The program(s) carried by an IP service can be displayed by clicking on the icon right on the left of the IP
service name (an IP service can contain several programs in case of MPEG-TS MPTS encapsulation).
To declare a new IP Service, click on the icon .
A new IP service can also be created by duplicating an existing one. Click on the icon on the left of the IP
service to be duplicated.
To start, stop, or delete an IP service, check the box on the left of its name , and select
the appropriate action:
.
Note that a list of consecutive service can be selected by clicking on the first service check box, and shift clicking
on the check box of the last service of the list.
Non consecutive services can be selected by CTRL clicking on their check boxes.
To edit an existing IP Service, click on the icon on the right end of the IP Service line.
The following window is displayed.
Parameter Type Description
Name Read/Write Name given to this IP service
Encapsulation Read/Write None: The IP Service includes one Program, and audio data are not encapsulated (raw
mode).
MPEG-TS SPTS: The IP Service includes one audio Program with Transport Stream
encapsulation.
MPEG-TS MPTS: The IP Service includes several audio Programs which are multiplexed in
a single MPEG-TS stream
Transport protocol Read/Write Available protocols are: RTP, UDP, HTTP, HLS.
HTTP is to be used for streaming to an Icecast/Shoutcast server. HLS is to be used to
stream to an HLS streaming server.
For low latency real time streaming, we recommend to select RTP.
UDP is to be used only if the equipment that receives the stream does not support standard
ACIP RTP streams.
