IQOYA SERV/LINK user manual
Use cases for clock configuration
133
related clock master.)
SERV/LINK use cases
Sync
source
PTP clock
source
PTP
properties
Destinations properties
Slave to the PTP clock from the
network. This PTP clock is delivered
by another device acting as Grand
Master
PTP
PTP Grand
Master
Slave only
checked
Master PTP on the network, with
synchro source from the WordClock
input
PTP
WordClock IN
“Slave only”
unchecked
Master PTP on the network, with
synchro source from internal clock
of
SERV/LINK
PTP
Internal
“Slave only”
unchecked
Master PTP on the network, with
synchro source from MADI
PTP
MADI
“Slave only”
unchecked
Slave to MADI
MADI
NA
NA
Syntonized checked
Slave to WordClock
WordClock
NA
NA
Syntonized checked
Slave to the internal clock
Internal
NA
NA
Syntonized checked
