IQOYA SERV/LINK user manual
63
Click on Save button to confirm the new Program.
To delete one or several unused programs, select them by clicking on the icon
on the left of their names, and
click on the button
on the top of the Programs list.
If all Programs are unused and you want to delete them all, click on the icon
on the left of the column title
“Program Name” (this selects all the Programs), and click on the button
on the top of
the Programs list.
Confirm or cancel your choice in the displayed confirmation window.
8.3.2 Send −> IP services
This page allows viewing and declaring the IP Services to be streamed over IP.
It can be accessed either from the left column
, or directly from the icon “Go to IP Service”
on the top right of the Programs page
.
In case some IP Services are already created, they are listed in the IP Services page, with their characteristics:
Name, Program, Tunneled ports, Tunneled GPIs, bitrate, FEC, Status.
●
Audio level exceeds the Signal threshold (dBfs) within the “Signal duration” analysis
window (ms).
●
Audio level does not stay below the Signal threshold during the “Signal drop duration”,
within the “Signal duration” analysis window.
Note the following rule: Signal drop duration <= (Signal duration / 2).
Once signal is recovered, the alarm “Analog audio in silent” or “Digital audio in silent” is reset (if
it is enabled from the “Alarms setup” menu).
