IQOYA SERV/LINK user manual
6 Accessing IQOYA SERV/LINK WEB pages
IQOYA SERV/LINK can be configured through its WEB pages.
For versions with analog and/or AES/EBU I/Os, configuration is done through one of the two network ports.
For versions with AES67 connectivity, the codec configuration is done from the two ports ETH0 and ETH1. The
AES67 parameters are configurable by connecting through the AES67 dedicated ports.
For the Dante version, the codec configuration is done from the two ports ETH0 and ETH1. The Dante
configuration is done via the Audinate’s Dante Controller software application, downloadable from Audinate’s
WEB site.
6.1 WEB pages for the configuration of the AES67 parameters (only for SERV/LINK with
AES67 or “AES67 & MADI” connectivity)
The AES67 parameters of IQOYA SERV/LINK can be configured from the AES67 Eth interfaces.
For an IQOYA SERV/LINK that supports up to 64 AES67 mono channels, there are two AES67 Eth ports:
● Eth0 port, enter https://192.168.2.100 (this is the default IP address).
● Eth1 port, enter https://192.168.3.100 (this is the default IP address).
See section “AES67 parameters configuration” in this document.
6.2 WEB pages for the configuration of the Dante parameters (only for SERV/LINK with
Dante connectivity)
The Dante parameters of IQOYA SERV/LINK can be configured from the Dante controller application, which is
available from the Audinate WEB site.
See section “Dante parameters configuration” in this document.
6.3 WEB pages for the configuration of the audio codecs and WAN parameters
From a WEB browser, connect to the IQOYA SERV/LINK WEB pages:
● for a network connection through Eth0 port, enter https://192.168.0.100 (this is the default IP address of
Eth0).
25
5.6 Steps to follow to configure IQOYA SERV/LINK in “Remote Broadcasting” mode of
use
● Set the network parameters of your IQOYA SERV/LINK
● Adjust the parameters of the audio inputs.
● Adjust the parameters of the audio outputs.
● Declare the SIP accounts
● Declare the IP codec instances
