IQOYA SERV/LINK user manual
11.6 CONFIGURATION OF THE AoIP PARAMETERS
The AES67 network parameters of SERV/LINK can be configured through its embedded WEB server, which is accessible from any of the
two AES67 “Eth A” ports.
In case of an IQOYA SERV/LINK 7272-AES67 platform, It is necessary to configure the AES67 parameters of the first group of 64
channels from one of the two “Eth A” ports, and to configure the AES67 parameters of the second group of 64 channels from one of the
two “Eth B” ports
11.6.1 Default IP addresses of AES67 Eth ports
From a PC connected to the AoIP network, and set to an IP address that belongs to the same subnetwork as an AES67 interface of
SERV/LINK, enter in your WEB browser the IP address of the AES67 interface the PC has access to.
The following page is displayed.
The parameters can be modified by clicking on Enable Edit Mode, on the top of the WEB page.
The requested password is: ravenna.
The following page is displayed;
130
Bank A: Eth0
Bank A: Eth1
Bank B: Eth0
Bank B: Eth1
192.168.2.100
192.168.3.100
192.168.4.100
192.168.5.100
