IQOYA SERV/LINK user manual
46
Click on “+Add VLAN” to declare a new VLAN.
Click on “Save” to save your modifications.
Parameter
Type
Description
Network interface
Read/Write
Select the network interface that will support the VLAN (Eth0, or Eth1, or bond)
VLAN ID
Read/Write
Enter the VLAN ID in the ranges [1-1001] [1006-4095]
Name
Read/Write
Enter a logical name for this VLAN
Status
Read/Write
Allows enabling/disabling this VLAN.
Select “Running” to enable this VLAN.
Select “Stopped” to disable this vLAN.
Priority
Read/Write
Enter the VLAN priority in the range [0-7].
IPv4 address
Read/Write
Enter the IP address of the selected Eth port in this VLAN.
If no value is entered, the IP address is the IP address of the selected Eth port.
Netmask
Read/Write
Enter the netmask for this VLAN interface.
If no value is entered, the netmask is the same as the selected Eth port netmask.
