IQOYA SERV/LINK user manual
103
○
“Failed”
: SIP is not activated and the IP codec instance is not ready for a symmetric RTP
connection probably because the audio listening port is not available.
9.2.2.2.1 Create a new IP codec instance
To create a new IP codec instance, click on
button, or create it from an existing one by clicking
the icon
on the left of this latter. Then provide the requested parameters and click on the
button. To
create several instances successively, click on
rather than on
. To cancel the creation of a
new IP codec instance, you can click on the
button at any time.
The requested parameters are described below:
● Parameters related to the audio I/Os
IP codec parameter
Type
Description
Number of channels
Read/Write
Number of audio channels managed by the IP codec instance. It can be
Mono or Stereo.
Audio I/O type
Read/Write
Type of the audio I/Os allocated to the IP codec instance. It can be
“Audio IO” for Analog or AES/EBU I/Os or “AoIP” for AES67 audio
channels.
First mono output channel
Read/Write
First mono audio output allocated to the IP codec instance. If the IP
codec instance is stereo, the next mono audio output is also allocated to
the instance. Audio outputs already allocated are greyed out in the
drop-down menu.
First mono input channel
Read/Write
First mono audio input allocated to the IP codec instance. If the IP codec
instance is stereo, the next mono audio input is also allocated to the
