IQOYA SERV/LINK user manual
14.1.3 ANALOG INPUTS
Only for “Analog & AES/EBU” versions
14.1.4 ANALOG OUTPUTS
Only for “Analog & AES/EBU” versions
14.1.5 AES/EBU INPUTS
Only for “Analog & AES/EBU” versions and for “AES/EBU” versions
14.1.6 AES/EBU OUTPUTS
Only for “Analog & AES/EBU” versions and for “AES/EBU” versions
14.1.7 SYNCHRONIZATION INPUTS
(*) Only for “Analog & AES/EBU” versions and for “AES/EBU” versions
14.1.8 MADI INPUTS/OUTPUTS
(*)Only for “MADI” versions and for “AES67-MADI” versions
150
Type
Balanced
A/D converter resolution
24 bits
Maximum input level/ impedance
+24 dBu/ >10 kΩ
Adjustable input gain
from –94.5dB à +24 dB
Type
Balanced
D/A converter resolution
24 bits
Maximum input level/ impedance
+24 dBu/ <100 Ω
Adjustable output gain
from –94.5dB à +24 dB
Hardware sample rate converters
Sample rate conversion = 7.5:1 to 1:8, up to 192 kHz
Programmable input gain
from –15 dB to +15 dB
Sample rate
32 kHz, 44.1 kHz, or 48 kHz
AES11(*)
Only on analog and AES/EBU I/O versions, and AES/EBU I/O versions
Word Clock
32, 44.1 kHz 48 kHz
Sample Rate
32, 44.1 kHz 48 kHz
MADI OUT channel mode (*)
64/64 channels mode
