IQOYA SERV/LINK user manual
31
8.1.1.2 Preferences −> System −> Audio Clock
This page allows defining the SERV/LINK sampling clock source .
For a SERV/LINK with AES/EBU I/Os, or both analog and AES/EBU I/Os, clock source can be:
● internal: on-board clock
● extracted from an AES/EBU input (AES In x - where x is the number of the AES/EBU input)
● AES Sync: AES11 synchro input
● Word clock input
For a SERV/LINK with MADI I/Os clock source can be:
● internal: on-board clock
● MADI
● Word clock input
Click on the “Device clock” field to selected the clock source.
For a SERV/LINK with AES67, or “AES67 & MADI” I/O’s, or Dante I/O’s,, the clock source is “Internal”.
The real clock source can be selected through the WEB pages accessible from:
● the AES67 network interfaces. See section “WEB pages for the configuration of the AES67 parameters”.
● The Dante controller application. See section “WEB pages for the configuration of the Dante parameters”.
Click on “Apply” to confirm your choice.
8.1.1.3 Preferences −> System −> Audio setup
This page allows setting the processing granularity and the working sampling frequency value IQOYA
SERV/LINK
