IQOYA SERV/LINK user manual
10 Managing sound files and playlists via FTP 127
11 AES67 parameters configuration 128
11.1 Principles 128
11.1.1 Embedded routing matrix 128
11.2 Sources 128
11.3 Destinations 129
11.4 Clock 129
Default routing matrix 129
11.6 CONFIGURATION OF THE AoIP PARAMETERS 130
11.6.1 Default IP addresses of AES67 Eth ports 130
11.6.2 Network settings 130
11.7 Global audio and clock settings 132
11.8 Routing matrix 134
11.9 Creation of IP streams published to the network 135
12 DANTE parameters configuration 137
12.1 Connecting to a Network 137
12.2 Using Dante Controller 139
12.3 AES67 compatibility mode 141
13 1+1 redundancy (High Availability) 143
13.1 What is High Availability (HA)? 143
13.2 Installation of a HA pair of IQOYA SERV/LINK 144
13.2.1 In what kind of application the HA service is to be used? 145
13.2.2 Configuration of the HA service 145
14 Specifications 148
14.1 Audio I/Os specifications 149
14.1.1 CONFIGURATION 149
14.1.2 CONNECTIVITY 149
14.1.3 ANALOG INPUTS 149
14.1.4 ANALOG OUTPUTS 150
14.1.5 AES/EBU INPUTS 150
14.1.6 AES/EBU OUTPUTS 150
14.1.7 SYNCHRONIZATION INPUTS 150
14.1.8 MADI INPUTS/OUTPUTS 150
14.1.9. ANALOG AUDIO PERFORMANCES
Only for “Analog & AES/EBU” versions 151
14.1.10 AES67 / RAVENNA / MADI parameters 151
14.1.11 RAVENNA / AES67 151
6
