Digigram Software for IQOYA SERV/LINK 88 (Upgrades from 8 Codecs to 16) User Manual
Page 80
IQOYA SERV/LINK user manual
80
To declare a new output program, click on
, or create it from an existing one by selecting the
icon
on the left of this latter.
Backup switching criteria
Program Parameter
Type
Description
Program
Program name
Read/Write
Name given to this output Program.
Disabled
Read/Write
Set this parameter to “Yes” if you want to disable the program. This means that IQOYA does not process it.
Set this parameter to “No” so that IQOYA processes this program and decodes audio.
Audio outputs
First output
Read/Write
Select the first audio output associated with this program.
Note that it is necessary to select an audio output that is not assigned to another program (an error is displayed)
First audio bus
Read/Write
Select the first audio bus channel associated with this program.
Audio bus is useful for IP stream transcoding.
Number of outputs
Read/Write
Set this parameter to 1 for mono, 2 for stereo, 6 for 5.1, 8 for 7.1.
Program Parameter
Description
IP stream loss duration
In case the codec is configured to decode an IP audio stream and at least one backup is defined, you can configure the
backup switching criteria.
IP stream loss duration
, expressed in ms, is the duration of absence of the stream. When this condition is encountered
on priority 1 or priority 2, IQOYA automatically switches to the lower priority.
The minimum value for this duration is the jitter value set from the Receive page.
IP stream recovery duration
This value, expressed in ms, is the duration of presence of the stream after it has been lost. When this condition is
encountered, IQOYA automatically switches to the higher priority where the stream is recovered.
