IQOYA SERV/LINK user manual
14 Specifications
14.1 Audio I/Os specifications
14.1.1 CONFIGURATION
14.1.2 CONNECTIVITY
(*) Only for AES67 and AES67-MADI versions
(**) Only for the Dante version
(***) Analog only for “Analog & AES/EBU” versions
(***) only for MADI and for AES67-MADI versions
149
Dimensions
19”, 1RU, 43.9 cm depth
Weight
7.9 kg
Power supply
2 hot swappable redundant PSU 90-264VAC
Optionally, 2 hot swappable redundant PSU -48VDC
Temperature
Operating 0°C 50°C, Storage -20°C TO 70°C
Humidity
Humidity 85% non-condensing
Power consumption
Max 80W
WAN Ethernet ports
2 x 10/100/1000 Mbps RJ-45
AES67 Ethernet ports(*)
2 x Gbps RJ-45
Dante Ethernet ports(**)
2 x Gbps RJ-45 (Primary and secondary)
Analog and AES/EBU audio inputs(***)
Female XLR on breakout cables
Analog and AES/EBU audio outputs (***)
Male XLR on breakout cables
MADI IN/OUT(****)
Multimode optical fiber
AES/EBU Sync
Female XLR
Word Clock Sync
BNC 75 Ohms
Optional RS232 ports (optional)
8 x SubD-D 9 per breakout cable
GPIO (Optional)
16 GPIs TTL compatible on terminal block
16 relay GPOs on terminal block
