Table 5. Printer Setup (continued)
Parameters Values Default
Graphics Print Direction Bidirectional
Unidirectional Bidirectional
Perforation Safety Disabled
Enabled Disabled
Jam Sensors Enabled
Disabled Enabled
Printer adjustment
Table 6 lists the parameters available for the Printer Adjustment Category. Refer to
Chapter 9, “Printer adjustments” for detailed information on setting these
parameters.
Table 6. Printer Adjustment
Parameters Values Default
Front AFTA* −5 to +3
Fixed 1 to 8 0
Front Tear Position −390 to +30 0
Front Left Margin Alignment 0 to 60 0
Front Paper Load Position −30 to +360 0
Rear AFTA*
(when optional second tractor is installed) −5 to +3
Fixed 1 to 8 0
Rear Tear Position
(when optional second tractor is installed) −390 to +30 0
Rear Left Margin Alignment
(when optional second tractor is installed) 0 to 60 0
Rear Paper Load Position
(when optional second tractor is installed) −30 to +360 0
*Fixed values in 0.5 increments (for example, Fixed 1, Fixed 1.5...Fixed 8)
Power On Reset
Table 7 lists the parameters available for the Power On Reset. Refer to Chapter 10,
“Power-On Reset (POR)” for detailed information on setting these parameters.
Table 7. Power On Reset
Parameters Values Default
Power On Reset Yes N/A
46 User’s Guide
