104 FTM-10R O
PERATING
M
ANUAL
Receiver
Circuit Type: FM / AM: Double-Conversion Super heterodyne
WFM: Triple-Conversion Super heterodyne
AM / FM Radio:Single-Conversion Super heterodyne
Intermediate Frequencies: FM / AM: 1st: 47.25 MHz, 2nd: 450 kHz
WFM: 1st: 45.8 MHz, 2nd: 10.7MHz, 3rd: 1MHz
FM Radio: 130 kHz, AM Radio: 50 kHz
Sensitivity: 5 µV TYP for 10 dB SN (0.5-1.7 MHz, AM)
2 µV TYP for 12 dB SINAD (76-108 MHz, WFM)
0.8 µV TYP for 10 dB SN (108-137 MHz, AM)
0.2 µV for 12 dB SINAD (137-140 MHz, FM)
0.2 µV for 12 dB SINAD (140-150 MHz, FM)
0.25 µV for 12 dB SINAD (150-174 MHz, FM)
1 µV TYP for 12 dB SINAD (174-222 MHz, WFM)
0.8 µV TYP for 10 dB SN (300-336 MHz, AM)
0.25 µV TYP for 12 dB SINAD (336-420 MHz, FM)
0.2 µV for 12 dB SINAD
(420-470 MHz, FM)
5 µV TYP for 12 dB SINAD (470-540 MHz, WFM)
5 µV TYP for 12 dB SINAD (540-800 MHz, WFM)
0.4 µV TYP for 12 dB SINAD (800-899.99 MHz, FM)
0.8 µV TYP for 12 dB SINAD (900 - 999.99 MHz, FM)
USA Version Cellular Blocked
Squelch Sensitivity: Better than 0.16 µV (144 / 430 MHz Band)
Selectivity : NFM, AM 12 kHz / 30 kHz (–6 dB / –60 dB)
AF Output: 8 W @ 4 Ohm for 10 % THD (@ 13.8 V) BTL EXP SP
4 W @ 4 Ohm for 10 % THD (@ 13.8 V) Normal EXP SP/CH
AF Output Impedance: 4-16 Ω
Specifications are subject to change without notice, and are guaranteed within the 144 and
430 MHz amateur bands only. Frequency ranges will vary according to transceiver ver-
sion; check with your dealer.
S
PECIFICATIONS
