58 FTM-10R O
PERATING
M
ANUAL
VOX S
ENSITIVITY
You may select the VOX sensitivity.
1. Press and hold the [VOL/SEL] key for one second to activate the Menu mode.
2. Rotate the DIAL knob to select Menu Item “F47 VOX SENS”.
3. Press the
key to enable selection of this Menu item.
4. Rotate the DIAL knob to select the desired sensitivity.
Available selections are “NORMAL”, “HIGH”, and “MAX”.
5. Press the [VOL/SEL] key to save the new setting and exit to normal operation.
L
ISTENING THE
AM/FM B
ROADCAST
S
TATION
1. Press the front panel / keys to switch the operating band to AM or FM.
2. Rotate the DIAL knob to select desired Broadcast station.
P When a signal is weak and difficult to hear, in some cases you may be able to hear better
by adjusting the squelch via the Menu Item “F38 SQL LEVL”. See page 31 for details.
P When using the optional BH-1 Bluetooth Headset with the FEP-4 Ear Phone or an after-
market stereo speaker, you may enjoy stereo listening from the FM Stereo Broadcast
Station or External Audio Input via the Menu Item “F42 STEREO”. See page 87 for details.
P You may adjust the receiver audio responses via the Menu Item “F3 AF PITCH”. See
page 85 for details.
P You may set the Automatic Audio Volume Controller to allow the most comfortable
and/or effective reception in noisy environments via the Menu Item “F1 AF AUTO”.
See page 56 for details.
P You may set the Volume Setting Alert feature via the Menu Item “F4 AF PRESET”.
See page 86 for details.
Note: When receiving AM Broadcast stations, the receive sensitivity may be poor when
using an antenna designed with a matching system that is a low DC impedance be-
tween the center and shield of the coax. For better AM reception, use an antenna that
does not present a low DC resistance to ground.
T
IME
-O
UT
T
IMER
(TOT)
The FTM-10R has the “Time-Out Timer” (TOT) feature that is designed to force the trans-
ceiver into the “receive” mode after a preset time of continuous transmission (the default is
“OFF”). This feature prevents your transceiver from transmitting a “dead carrier” for a long
time if the microphone PTT switch is accidentally locked in the “TX” condition. The Time-Out
Timer “switch-to-receive” time may be adjusted from 1 to 30 minutes, or Off via Menu Item.
1. Press and hold the [VOL/SEL] key for one second to activate the Menu mode.
2. Rotate the DIAL knob to select Menu Item “F43 TOT”.
3. Press the
key to enable selection of this Menu Item.
4. Rotate the DIAL knob to select the desired interval. Available selections are 1 to 30
minutes, or Off.
5. Press [VOL/SEL] key to save the new setting and exit to normal operation.
When your transmission time is within 10 seconds of the Time-Out Timer expiration, an
alert bell will provide an audible warning from the speaker.
C
ONVENIENCE
F
EATURES
