Yaesu FTM-10R - Manual (Page 59)

57 FTM-10R O
PERATING
M
ANUAL
C
ONVENIENCE
F
EATURES
AF-VFO
FEATURE
By default, the volume control (DIAL knob) and Clock display not return to the frequency
control automatically when you leave an interval of approximately three seconds. You may
change the status of the DIAL knob so that the display will return automatically to the
Frequency select dial function and Frequency display.
1. Press and hold the DIAL key for one second to activate the Menu mode.
2. Rotate the DIAL knob to select Menu Item “F5 AF-VFO”.
3. Press the
key to enable selection of this Menu Item.
4. Rotate the DIAL knob to select the desired mode.
TOGGLE : Keeps the DIAL knob function and display
until the [VOL/SEL] key is pressed once again.
AUTOBACK : The DIAL knob function and display comes
back to frequency selection and frequency
display approximately three seconds after.
Press the DIAL key for one second to save the new setting and exit to normal operation.
VOX O
PERATION
The VOX system provides automatic transmit/receive switching based on voice input to the
microphone. With the VOX system enabled, you do not need to press the PTT key in order
to transmit.
1. Press and hold the [VOL/SEL] key for one second to activate the Menu mode.
2. Rotate the DIAL knob to select Menu Item “F46 VOX MIC”.
3. Press the
key to enable selection of this Menu Item.
4. Rotate the DIAL knob to select the one of the following
microphone functios.
R-HAND : Enable the VOX operation for the microphone
which is connected to the rear panel MIC Jack.
F-HAND : Enable the VOX operation for the microphone
which is connected to the front panel MIC Jack.
FRONT : Enable the VOX operation for the front panel microphone.
VOX OFF : Disable the VOX operation.
5. Press the [VOL/SEL] key to save the new setting and exit to normal operation.
To disable the VOX operation, just repeat the above procedure, rotating the DIAL knob to
select “VOX OFF” in step 4 above.
P If the VOX feature is activated by background noise, adjust the VOX gain via the Menu
Item “F47 VOX SENS”. See page 58 for details.
P When the transceiver audio is output to the speaker, the VOX will not activate the
transmitter even if you talk directly into the microphone.
