40
FTM-10R O
PERATING
M
ANUAL
S
QUELCH
L
EVEL
The FTM-10R allows setting the squelch threshold level.
1. Press the front panel
key to switch the Memory mode, if needed.
2. Press and hold the
key for one second to enter the Memory Channel Customization
mode.
3. Rotate the DIAL knob to select Menu Item “M7 SQL LEVL”.
4. Press the
key briefly. Then rotate the DIAL knob to
select the desired squelch threshold level (“SQL OFF” ~ “SQL
MAX
”).
5. Press the [VOL/SEL] key to save the new setting and re-
turn to the memory recall mode.
CTCSS
FREQUENCY
The FTM-10R enables you to change the CTCSS Tone frequency.
1. Recall the memory channel on which you wish to change the CTCSS Tone Frequency.
2. Press and hold the
key for one second to enter the Memory Channel Customization
mode.
3. Rotate the DIAL knob to select Menu Item “M8 SQL TSQF”.
4. Press the
key to display the current CTCSS Tone Fre-
quency.
5. Rotate the DIAL knob to select desired CTCSS Tone Fre-
quency.
6. Press the [VOL/SEL] key to save the new setting and re-
turn to the memory recall mode.
M
EMORY
O
PERATION
67.0
69.3
71.9
74.4
77.0
79.7
82.5
85.4
88.5
91.5
94.8
97.4
100.0
103.5
107.2
110.9
114.8
118.8
123.0
127.3
131.8
136.5
141.3
146.2
151.4
156.7
159.8
162.2
165.5
167.9
171.3
173.8
177.3
179.9
183.5
CTCSS TONE FREQUENCY (Hz)
186.2
189.9
192.8
196.6
199.5
203.5
206.5
210.7
218.1
225.7
229.1
233.6
241.8
250.3
254.1
