Luetooth, Peration, 60 ftm-10r o – Yaesu FTM-10R User Manual
Page 62: Pairing
60
FTM-10R O
PERATING
M
ANUAL
When the optional BU-1 Bluetooth
®
Adapter Unit is installed, the FTM-10R is enabled to
send/receive voice messages with the optional BH-1 Bluetooth
®
Headset via wireless links.
Pairing
When using the Bluetooth
®
Headset for the first time, the Bluetooth
®
Headset and the
FTM-10R must be paired.
1. Turn the transceiver off.
2. Press and hold the [POWER] key while turning the power on again.
3. Press and hold the [VOL/SEL] key for one second to activate the Menu Mode.
4. Rotate the DIAL knob to select the Bluetooth
®
Adapter Unit you wish to pair.
Main Chassis’s Bluetooth
®
Adapter Unit: Menu Item “SF6
BLTH R
”
Front Panel’s Bluetooth
®
Adapter Unit: Menu Item “SF7
BLTH F
”
5. Press the PTT key.
The current PIN code appears.
When perform pairing of BH-1 Bluetooth
®
Headset, skip
to the next step. Otherwise, set the PIN number of the
Bluetooth
®
Unit:
1. Following operation of step 4 (press the PTT key), ro-
tate the DIAL knob to set the first digit of the PIN code.
2. Press the
key to save the first digit of the PIN code and move on to the next
place.
3. Repeat the previous steps to complete the PIN code. If you make a mistake, press the
key to move back to the incorrect number, then re-enter the correct number.
6. Press and hold the power switch on the BH-1 Bluetooth
®
Headset until the BH-1’s
indicator blinks red/blue alternately.
7. Press the PTT key on the FTM-10R to initiate the pairing.
8. If the pairing is successful, “LINK OK” notation will appear on the display. The FTM-
10R will turn off and back on again.
When the BH-1 Bluetooth
®
Headset is correctly recognized by the FTM-10R , the
BH-1’s indicator will blink blue.
B
LUETOOTH
O
PERATION
