To transmit the memorized telephone number:
1. Press the PTT key, then press and hold the
key while transmitting.
The “DT MEM” indication will appear in the display for a
moment (thus enabling the DTMF AutoDial), and “ ” icon
will appear in the display.
2. Press the
key while maintaining a transmission.
3. Rotate the DIAL knob to select the DTMF AutoDial memory channel number you wish
to transmit (“D1” to “D9”) while maintaining a transmission.
4. Press the
key again while maintaining a transmission.
P
The telephone number is transmitted.
P
If you use the optional DTMF hand Microphone “MH-68
A6J
”, you may send the
telephone number using the following steps:
1. First press the PTT key, then press the microphone’s numeric keys ([1] through
[9]) corresponding to the DTMF memory string you wish to send.
2. Once the string begins, you may release the PTT key, as the transmitter will be
held “on the air” until the DTMF string is completed.
P
The transmitter will hold for 1.5 seconds after completion of the DTMF Memory
string.
When the transmission is completed, press and hold the
key while transmitting to elimi-
nate the “ ” icon.
DTMF A
UTODIALER
