DTMF A
UTODIALER
Nine Autodialer memories are available on the FTM-10R. These DTMF Autodialer memories
can store up to 16 digits of a telephone number for repeater autopatch or other use.
To load the DTMF Autodialer memories:
1. Press and hold the [VOL/SEL] key for one second to activate the Menu mode.
2. Rotate the DIAL knob to select Menu Item “F13 DTMF”.
3. Press the
key to enable selection of this Menu item.
4. Rotate the DIAL knob to select the DTMF AutoDial memory
channel number into which you wish to store a telephone
number (“D1” to “D9”). The previously stored telephone
number is displayed on the LCD.
5. Press and hold the key for one second.
Press the PTT key to clear any previously stored telephone
number, if desired.
6. Rotate the DIAL knob to select the first digit of the tele-
phone number you wish to store. Then press the key
momentarily to save the first digit of the telephone number
and move on to the next digit.
“E” representing DTMF “*” and “F” representing DTMF
“#”
7. Repeat previous step for each digit in the telephone number. If you make a mistake,
press the key to move the cursor back to the previous digit, then re-enter the correct
number.
Press the PTT key to delete all data after the cursor that may have been previously
stored erroneously.
8. When entries of all digits are complete, press and hold the key for one second.
9. If you wish to store another DTMF string, repeat steps 4 through 8 above.
10. Press the [VOL/SEL] key momentarily to save the new setting and exit to normal op-
eration.
