32 FTM-10R O
PERATING
M
ANUAL
S
MART
M
ENU
F
EATURES
TCALL
(Default “OFF”)
You may enable TCALL if the repeaters in your country require a 1750-Hz burst tone for
access.
1. Press the top panel / key to select “TCALL”.
2. Press the key.
The transmitter will automatically be activated, and a 1750-Hz audio tone will be super-
imposed on the carrier.
3. You may release the key, and use the PTT key for activating the transmitter there-
after.
TX P
OWER
S
ELECT
Set the TX Power level to reduce battery drain and use the lowest power necessary to
maintain reliable communications.
1. Press the top panel / key to select “TX POWER”.
2. Press the key repeatedly to select the desired transmit
power level.
You may set the transmit power level for the 144 MHz and
430 MHz band individually.
HIGH MID LOW
144 MHz 50 W
20 W 5 W
430 MHz 40 W
3. Two seconds after selecting the transmitter power level, the new setting is automatically
saved and the radio returns to the VFO or Memory Channel mode.
When the
key function is set to “TX POWER” via the top panel / key, the
key may be used as the Transmit Power Level control key.
I
NTERCOM
V
OLUME
C
ONTROL
1. Press the top panel / key to select “VOL.ITCOM”.
2. Press the key to change the Intercom receiver audio volume level between “HIGH”
and “LOW”.
3. Two seconds after selecting the Intercom receiver audio volume level, the new setting is
automatically saved and the radio returns to the VFO or Memory Channel mode.
When the
key function is set to “VOL.ITCOM” via the top panel / key, the
key may be used as the Transmit Power Level control key.
